13. Technical Data of the DPSI BMS
Current Sources all available battery types (NiMH, NiCad, LiPo
etc.)
Operating Voltage Range 5.5V.... 16.8V
Nominal Input Voltage 6.0V.... 16.0V
Turn On Procedure Automatically @ I1>150mA or by button
Turn Off Procedure Automatically @ I1<150mA or by button
Quiescent Current (Turned Off State) Approx. 12µA battery 1 / approx. 7µA battery 2
Current Consumption (Turned On) Approx. 30mA battery 1
approx. 16mA battery 2
Max. Constant Current per Channel 10A (Flow Rate)
Max. Peak Current per Channel (10ms) 30A (Flow Rate)
Voltage Drop @ 5A 100mV
Galvanically Separation Both batteries totally decoupled
CE-Test According to 89/336/EWG
Environmental Conditions (Operating) +14°F.... +122°F
Permissible Temperature Range -13°F.... +185°F
Display Range Battery Voltage 4.0V ... 20.0V (or >20.0V)
Display Range Battery Current 0.15A ... 13.00A (or >13.00A)
Display Range Battery Capacity 0mAh ... 9999mAh (or >9999mAh)
Display Range Battery Flight Time 0min ... 9999min (or >9999min)
Non Volatile Memory (resetable) Withdrawn Capacity, Flight Time (Turn On Time)
Dimension (Width x Height x Depth) 4.1” x 1.4” x 1.2”
4.1” x 1.4” x 1.5” (incl. bracket)
Screw Diameter for Mounting 2x 0.12” (for M3 screws with Stop nuts)
Hole Spacing for Mounting 3.5”
Hole Cutout for Mounting 3.1” x 1.25”
Weight Approx. 2 oz.
Housing Material ABS impact resistant
Warranty 24 month
