Emec VMS MF Series - Flow Rate Curves

44
Flow rate
curves
All flow rate indications refer to measurements made with H
2
O at 20 °C at the
indicated back pressure.
The dosing accuracy is ± 2% at a constant pressure of ± 0.5 bar.
Fig. 40. VMS MF flow rate curves
2001: l/h 1 bar 20
Pump body mod. J
L/h
1802: l/h 2 bar 18
Pump body mod. K
L/h
bar
bar
1804: l/h 4 bar 18
Pump body mod. K
L/h
1504: l/h 4 bar 15
Pump body mod. K
L/h
bar
bar
1502: l/h 2 bar 15
Pump body mod. K
L/h
1005: l/h 5 bar 10
Pump body mod. K
L/h
bar
bar
1010: l/h 10 bar 10
Pump body mod. K
L/h
1004: l/h 4 bar 10
Pump body mod. K
L/h
bar
bar
