INTRODUCTION
VMS MF series VMS MF is the multifunctional series because it allows different working modes
to be set: Constant, Divide, Multiply, ppm, perc, mlq, batch, volt, mA, Timer.
In addition, you can:
-
set an upkeep dosing in case of system downtime (ppm menu - upkeep setting)
The pump is equipped with:
-
LEVEL input (level control)
Pump dosing is determined by the number of pulses and the capacity per single
injection. Single injection adjustment is linear only over values between 30%
and 100%.
The operating and control parameters are shown on an LCD display and managed
via a keypad.
Some features described in this manual may require the use of
additional accessories (not included).
VMSA MF series The VMSA MF dosing pump is the self-purging pump body version of the VMS MF pump.
The use of a self-purging pump body is necessary for dosing gas-
generating chemicals (e.g. hydrogen peroxide, ammonia, sodium
hypochlorite at certain temperatures).
For installation ⎘"“Connecting hydraulic components on self-purging mod. VMSA MF”.
Package
contents
4 dowels ø6
4 self-tapping screws 4.5 x 40
1 delay fuse 5 X 20
1 level probe with axial foot filter (PVDF)
1 injection valve (PVDF) calibrated to 0.3 bar
2 m delivery hose* (matt PE)
2 m suction hose* (PVC)
2 m bleed hose (clear PVC 4x6)
1 operating manual
* If the measurement is 6x8, there is only one 4-metre opaque hose.
Cut to obtain the two hoses.
