Emerson FB2200 Flow Computer Instruction Manual
D301784X012
March 2019
Service and Troubleshooting 99
Figure 5-9. Remove the Termination Cover (if present)
7. A strap with a hook and loop fastener holds the battery in place. Unstrap the battery but
leave the connectors on the current battery connected. Gently lift the battery with the
battery cable attached out of the compartment.
Figure 5-10. Unstrap the Old Battery Pack – Leave Connected to Cable
8.
Place the old battery on top of the flow computer enclosure and place the new battery next
to it.
