Emerson Daniel Series User Manual

Table 2-7: 2818 Dual channel preamplifier configuration
Plug component designator Terminal connections Description
TB1 - Customer connection 1 +10 to 30 Vdc
2 Common
3 Common
4 Channel A output
5 Channel B output
6 TTL out A
7 TTL out B
TB2 - Channel A pickoff (1) 1 White
2 Red
TB3 - Channel B pickoff (1) 1 White
2 Red
Table 2-8: 2415 Intrinsically safe preamplifier configuration
Designator Terminal connections Description
Customer connection 1 Supply voltage
2 Common
3 Output signal (half frequency)
4 Output signal
Pickoff (1) 5 White
6 Red
Table 2-9: 1815B Zero crossing preamplifier configuration
Designator Terminal connections Description
Customer connection 1 Supply voltage
2 Common
3 Output signal (x1)
4 Output signal (x2)
Pickoff (1) 5 White
6 Red
Table 2-10: 1817X Bi-directional preamplifier configuration
Designator Terminal connections Description
Customer connection 1 Supply voltage
2 Common
User manual Operating conditions and specifications
P/N 3-9008-515 March 2019
User manual 49

Emerson Daniel Series Specifications

General

Type	Flow Meter
Repeatability	±0.1% of reading
Communication Protocol	HART, Modbus, Foundation Fieldbus
Output	4-20 mA, pulse, frequency
Process Connection	Flanged, wafer, threaded
Material	Stainless steel, carbon steel, Hastelloy
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Protection Rating	IP67, NEMA 4X
Fluid Compatibility	Liquids, gases
