Emerson Daniel Series User Manual

Table 2-12: Flow meter and flow straightening section dimensions for the Series
1500 LTM NPS 3-24 (continued)
Size D E F
Inches mm Inches mm Inches mm
8 80 2032 40 1016 136 3454.4
10 100 2540 50 1270 170 4318.0
12 120 3048 60 1524 204 5181.6
16 160 4064 80 2032 272 6908.8
18 180 4572 90 2286 306 7772.4
20 200 5080 100 2540 340 8636.0
24 240 6096 120 3048 408 10363.2
Table 2-13: Weight table for the stainless steel LME
Size ANSI class 150 ANSI class 300 ANSI class 600
Lbs Kg Lbs Kg Lbs Kg
3 42 19.1 52 23.6 56 25.6
4 56 25.6 78 35.6 97 44.1
6 89 40.6 122 55.6 180 81.6
8 131 59.6 191 86.6 285 129.6
10 217 98.6 290 131.6 468 212.6
12 331 150.6 444 201.6 598 271.6
16 736 334.6 846 384.6 1264 574.6
18 1104 501.6 1165 529.6 1662 755.6
20
(1)
CF CF CF CF CF CF
24
(1)
CF CF CF CF CF CF
(1) CF: Consult factory
User manual Operating conditions and specifications
P/N 3-9008-515 March 2019
User manual 53

Emerson Daniel Series Specifications

General

Type	Flow Meter
Repeatability	±0.1% of reading
Communication Protocol	HART, Modbus, Foundation Fieldbus
Output	4-20 mA, pulse, frequency
Process Connection	Flanged, wafer, threaded
Material	Stainless steel, carbon steel, Hastelloy
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Protection Rating	IP67, NEMA 4X
Fluid Compatibility	Liquids, gases
