Table 4-3: Preamplifier power requirements (continued)
Power requirement
type
Description
Intrinsically safe
preamplifier
Inputs Supply voltage: 13-25 Vdc @ ≤12 mA
Sensor type: Reluctance
Signal: Sine wave
Preamplifier sensitivity:
• 60 mVpp
• 10Hz - 1KHz (60mVpp)
• 10Hz - 3KHz (115mVpp)
• 10Hz - 5KHz (200mVpp)
Temperature range: -40 ºC to 85 ºC (-40 ºF to 185 ºF)
Outputs Powered pulse output:
• Type: Square wave
• Frequency range: ~5 Hz to 5 kHz
• Amplitude: 0 to 5 V
Zero crossing
preamplifier
Inputs Supply voltage: 14-30 VDC
Sensor type: Reluctance
Signal: Sine wave
Preamplifier sensitivity: 40 mVpp
Temperature range: -40 ºC to 85 ºC (-40 ºF to 185 ºF)
Outputs Powered pulse output:
• Type: Square wave
• Frequency range: ≤ 5 kHz
• Amplitude: 0-12 V
Bi-directional
preamplifier
Inputs Supply voltage: 11.5-36 VDC
Sensor type: Reluctance
Signal: Sine wave
Preamplifier sensitivity: 40 mVpp
Temperature range: -40 ºC to 85 ºC (-40 ºF to 185 ºF)
Outputs Powered pulse output:
• Type: Square wave
• Frequency range: ≤ 5 kHz
• Amplitude: 0-Vs
4.3.5 Grounding
Ground the turbine meter electronics internally for safe operation. Connect a wire to the
chassis ground lug located inside the LME as the primary ground. A secondary ground is
located outside of the LME. Refer to Figure 4-4 and Figure 4-5. Digital grounds should
never be connected to chassis ground.
Prepare the turbine meter for use User manual
March 2019 P/N 3-9008-515
64 Daniel Series 1500 Liquid Turbine Meter, NPS 3-24

Emerson Daniel Series Specifications

General

Type	Flow Meter
Repeatability	±0.1% of reading
Communication Protocol	HART, Modbus, Foundation Fieldbus
Output	4-20 mA, pulse, frequency
Process Connection	Flanged, wafer, threaded
Material	Stainless steel, carbon steel, Hastelloy
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Protection Rating	IP67, NEMA 4X
Fluid Compatibility	Liquids, gases
