Emerson EV2000 Series User Manual

104 Appendix 1 Parameters
EV2000 Series Universal Variable Speed Drive User Manual
Group F9: Enhanced Functional Parameters
Para. Name LCD Display Setting range Unit
Factory
setting
Modif.
F9.21
Frequency
decrease rate at
voltage
compensation
FREQ SLOW
RATE 1
0.00~99.99Hz/s 0.01Hz/S 10.00Hz/s
○
F9.22
Function of
restart after
power failure
RESTART
AFTER
POFF
0:Disabled
1:Enabled
1 0
×
F9.23
Delay time for
restart after
power failure
DELAY TIME
BEFORE
RESTART
0.0~10.0s 0.1s 0.5s
○
 Note:
① Actual length(km)=
﹛
counting value* Perimeter of axis(F9.18)/ Number of pulses per cycle(F9.19)
﹜
* Ratio of
length(F9.16)/calibration coefficient of length(F9.17)/100/1000.
② Functions of F9.14~F9.19 are only valid for the drive of 45kW or below.
Group FA: Reserved Parameters
Parameter Name LCD Display Setting range Unit Factory setting Modification
FA.00~FA.11 Reserved RESERVED - - 0 *
Group FF: Communication Parameters
Para. Name LCD Display
Setting range Unit
Factory
setting
Modif.
FF.00
Communication
configuration
COMM CONFIG
Unit’s place of LED: Baud rate selection
0:300bps 1:600bps
2:1200bps 3:2400bps
4:4800bps 5:9600bps
6:19200bps 7:38400bps
Ten’s place of LED: Data format
0:1-8-1 format, no parity
1:1-8-1 format, Even parity
2:1-8-1 format, Odd parity
Hundred’s place of LED: virtual input terminal
0:Disabled 1: Enabled
Thousand’s place of LED: wiring mode
0:Direct connection via cable (RS232/485)
1: MODEM (RS232)
1 0005
×
FF.01 Local address LOCAL ADDR 0~126,127 is the broadcasting address 1 1
×
FF.02
Time threshold for judging
the communication status
TIMEOUT
SETTING
0.0~1000s 0.1 0.0s
×
FF.03
Delay for responding to
control PC
SCI REPLY
DELAY
0~1000ms 1 5ms
×
Group FH: Motor Parameters
Para. Name LCD Display Setting range Unit Factory setting Modif.
FH.00
Number of polarities of
motor
MOTOR POLARITY
NUM
2~14 2 4
×
FH.01 Rated power RATED POWER 0.4~999.9kW 0.1kW Dependent on drive’s model
×
FH.02 Rated current RATED CURR 0.1~999.9A 0.1A Dependent on drive’s model
×
FH.03 Current without load CURR WITH NO LOAD 0.1~999.9A 0.1A Dependent on drive’s model
×
FH.04 Resistance of stator R1 STATOR RESIS R1 0.00%~50.00% 0.01% Dependent on drive’s model
○
FH.05 Leakage inductance X LEAKAGE INDUC X 0.00%~50.00% 0.01% Dependent on drive’s model
○
