Emerson EV2000 Series User Manual

Appendix 1 Parameters 103
EV2000 Series Universal Variable Speed Drive User Manual
Group F9: Enhanced Functional Parameters
Para. Name LCD Display Setting range Unit
Factory
setting
Modif.
F9.05
Frequency
adjustment
FREQ ADJ
0:Disabled 1:Percentage of F005
2:Percentage of present frequency
1 0
○
F9.06
Adjustment
coefficient of
reference
frequency
ADJ
FACTOR
0.0%~200.0% 0.1% 100.0%
○
F9.07 Function of keys
KEY FUNC
SELE
Unit’s place of LED:STOP/RESET key’s function selection
0:Valid in panel control mode
1:Stop in stopping mode in panel, terminal and serial port control
mode
2:Coast to stop in non-panel control mode, stop in stopping mode
in panel control mode
Ten’s place of LED: function of PANEL/REMOTE key
0:Inactive
1:Stopping status active
2:Valid in stopping and running modes
Hundred’s place of LED: Keypad locking function
0:No locking
1:Locked
2:All the keys except the STOP/RESET key are locked
3:All the keys except the SHIFT key are locked
4:All the keys except the RUN and STOP/RESET keys are
locked
1 000
×
F9.08
Cooling fan
control
FAN CTR
0:Auto operation mode
1:Fan operate continuously when power is on
Note: Continue to operate for 3 minutes
1 0
×
F9.09
Unit of
Accelerating/dec
elerating time
ACC/DEC
UNIT
0: Second 1: Minute 0 0
×
F9.10 Drop control DROOP CTR 0.00~10.00Hz 0.01Hz 0.00Hz
○
F9.11
Overshoot
enabled
OVER
MODULATIO
N ENABLE
0:Disabled
1:Enabled
1 1
×
F9.12
Zero-frequency
operation
threshold
ZERO FREQ
THRESHOLD
0.00~650.00Hz 0.01Hz 0.00Hz
○
F9.13
Zero-frequency
hysteresis
ZERO FREQ
HYSTERESIS
0.00~650.00Hz 0.01Hz 0.00Hz
○
F9.14
Reference
length
(Stop at fixed
length)
LENGTH
SET
0.000(function of stopping at fixed length is disabled)~65.535km 0.001km 0.000km
○
F9.15
Actual length
(Saving at power
off)
LENGTH 0.000~65.535km( saving at power off) 0.001km 0.000km
○
F9.16 Ratio of length
LENGTH
SCALE
0.001~30.000 0.001 1.000
○
F9.17
Length
correction
coefficient
LENGTH
CALIBRATION
0.001~1.000 0.001 1.000
○
F9.18 Perimeter of axis SHAFT GIRTH 0.01~100.00cm 0.01cm 10.00cm
○
F9.19
Number of
pulses per cycle
PULSES
PER CYCLE
1~9999 1 1
○
F9.20
Trip-free
operating
function
NO STOP
DURING
P.OFF
0: Disabled
1: Enabled (low voltage compensation)
(Valid for the drive below 15kW)
1 0
×
