10 Chapter 2 Product Introduction
EV2000 Series Universal Variable Speed Drive User Manual
2. Mechanical parameters
Table 2-4 Mechanical parameters 1
EV2000-4T0055G/0075P～EV2000-4T0450G1/0550P1、EV2000-4T0550G、EV2000-4T0750G、EV2000-4T0750P、
EV2000-4T0900P、EV2000-4T0900G、EV2000-4T1100P
Drive model (55P or below)
(G: constant torque, P: Fan & pump)
Motor
(kW)
A
(mm)
B
(mm)
H
(mm)
W
(mm)
D
(mm)
Diameter of
mounting
hole(mm)
Fig.
Number
Gross
weight(kg)
EV2000-4T0055G/0075P
5.5/7.5
186 285 300 200 202 6.8 Fig. a 7.5
EV2000-4T0075G/0110P
7.5/11
EV2000-4T0110G/0150P
11/15
236 365 380 250 209 6.8 Fig. a 12
EV2000-4T0150G/0185P
15/18.5
EV2000-4T0185G1/0220P1 18.5/22
180 421 435 275 209 7 Fig. b
13
EV2000-4T0220G1/0300P1 22/30 15
EV2000-4T0300G1/0370P1 30/37
250 600 624 375 262 9 Fig. b 35
EV2000-4T0370G1/0450P1 37/45
EV2000-4T0450G1/0550P1 45/55 38
EV2000-4T0550G _
55 300 747 770 468 301 10 Fig. d 50
EV2000-4T0750G EV2000-4T0750P
75 300 747 770 468 301 10 Fig. d 50
EV2000-4T0900G EV2000-4T0900P
90 300 747 770 468 301 10 Fig. d 90
EV2000-4T1100P
110 300 747 770 468 301 10 Fig. d 90
Table 2-5 Mechanical parameters 1
EV2000-4T1100G~EV2000-4T2200G. EV2000-4T2200P. EV2000-4T2800P
Drive model
Motor
(kW)
A
(mm)
B
(mm)
H
(mm)
W
(mm)
D
(mm)
Diameter of
mounting holes
(mm)
Fig.
Number
Gross
weight (kg)
Constant torque Fan & pump
EV2000-4T1100G - 110 370 855 880 530 370 14
Fig. e
100
EV2000-4T1320G EV2000-4T1320P 132 370 855 880 530 370 14 100
EV2000-4T1600G EV2000-4T1600P 160 370 855 880 530 370 14 100
- EV2000-4T2000P 200 370 855 880 530 370 14 100
EV2000-4T2000G - 200 520 975 1000 680 370 14 140
EV2000-4T2200G EV2000-4T2200P 220 520 975 1000 680 370 14 140
- EV2000-4T2800P 280 520 975 1000 680 370 14 140
Notes:
1. Models in Table 2-5 are under developing.
2. For 75kWG drive or above, DC reactor is included in its standard configuration. The weight of DC reactor in the above table is
not included in the gross weight. Outline and dimensions of DC reactor are shown below.
