Emerson Fisher FIELDVUE DVC6000f User Manual

DVC6000f Digital Valve Controllers
December 2009
4-182
Table 4-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Status Options STATUS_OPTS
AI 14 4-130, 4-135
AO 15 4-76
DI 14 4-167
DO 15 4-155
ISEL 10 4-104, 4-107, 4-109
OS 13 4-124
PID 14 4-90
Standby Firmware Revision STBY_FIRMWARE_REV Resource 55 4-7, 4-18, 6-6
StdDev STDDEV
AI 39 4-132, 4-137
AO 31 4-78
PID 75 4-96
Strategy STRATEGY
AI 3 4-134
AO 3 4-75
DI 3 4-166
DO 3 4-154
ISEL 3 4-109
MAI 3 4-143
OS 3 4-123
PID 3 4-89
Resource 3 4-6, 4-12, 6-5
Transducer 3 4-42
Stroking Time Close STROKING_TIME_CLOSE Transducer 85.9 4-39, 4-62
Stroking Time Open STROKING_TIME_OPEN Transducer 85.8 4-39, 4-62
Structureconfig STRUCTURECONFIG PID 71 4-86, 4-95
Supply Pressure Hi Alert Point
SUP_PRES_HI_ALRT_PT Transducer 76.8 4-30, 4-58
Supply Pressure Lo Alert Point
SUP_PRES_LO_ALRT_PT Transducer 76.9 4-31, 4-58
Supply Pressure Offset SUPP_PRESS_OFFSET Transducer 46.2 4-49
Supply Pressure Scale SUPP_PRESS_SCALE Transducer 46.1 4-49
Supply Pressure Status
Supply Pressure
SUPPLY_PRESSURE
STATUS
VALUE
Transducer
35
35.1
35.2
4-30, 4-45, 6-12
T Aoperiods
T_AOPERIODS PID 92 4-97
T Auto Extra DT
T_AUTO_EXTRA_DT PID 90 4-97
T Auto Hysteresis
T_AUTO_HYSTERESIS PID 91 4-97
T Gain Magnifier
T_GAIN_MAGNIFIER PID 89 4-96
T Hyster
T_HYSTER PID 87 4-96
T Ipgain
T_IPGAIN PID 80 4-96
T Pdtime
T_PDTIME PID 85 4-96
T Psgain
T_PSGAIN PID 83 4-96
T Ptimec
T_PTIMEC PID 84 4-96
T Relayss
T_RELAYSS PID 88 4-96
T Request
T_REQUEST PID 77 4-96
T State
T_STATE PID 78 4-96
T Status
T_STATUS PID 79 4-96
T Targetop
T_TARGETOP PID 86 4-96
T Ugain
T_UGAIN PID 81 4-96
T Uperiod T_UPERIOD PID 82 4-96
−Continued−
4

Emerson Fisher FIELDVUE DVC6000f Specifications

General

Brand	Emerson
Model	Fisher FIELDVUE DVC6000f
Category	Controller
Language	English
