Emerson Fisher FIELDVUE DVC6000f User Manual

All Blocks
December 2009
4-183
Table 4-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Tag Description TAG_DESC
AI 2 4-134
AO 2 4-75
DI 2 4-166
DO 2 4-154
ISEL 2 4-109
MAI 2 4-143
OS 2 4-123
PID 2 4-89
Resource 2 4-6, 4-12, 6-5
Transducer 2 4-35, 4-42
Target Travel Status
Target Travel
TRAVEL_TARGET
STATUS
VALUE
Transducer
49
49.1
49.2
4-49
Temperature TEMPERATURE Transducer 48 4-31, 4-49, 6-11
Temperature Units TEMPERATURE_UNITS Transducer 89 4-36, 4-63
Temperature Hi Alert Point TEMP_HI_ALRT_PT Transducer 76.6 4-31, 4-58
Temperature Lo Alert Point TEMP_LO_ALRT_PT Transducer 76.7 4-31, 4-58
Test Read Write TEST_RW Resource 8 4-12
Time Since Reset TIME_SINCE_RESET Resource 53 4-17
Tracking Input Discrete TRK_IN_D PID 38 4-86, 4-92
Tracking Scale TRK_SCALE PID 37 4-86, 4-92
Tracking Value TRK_VAL PID 39 4-83, 4-86, 4-92
Transducer Directory TRANSDUCER_DIRECTORY Transducer 9 4-43
Transducer Error XD_ERROR Transducer 11 4-43
Transducer Scale XD_SCALE
AI 10 4-130, 4-134
AO 12 4-76
Transducer State XD_STATE
DI 10 4-167
DO 12 4-155
Transducer Type TRANSDUCER_TYPE Transducer 10 4-43
Travel Accumulator TRAVEL_ACCUM Transducer 72 4-34, 4-53, 6-11
Travel Always TRAVEL_ALWAYS Transducer 100 4-63
Travel (D) Status
Travel (D)
TRAVEL_D
STATUS
VALUE
Transducer
33
33.1
33.2
4-44, 6-11
Travel Enable TRAVEL_ENABLE Transducer 75.4 4-57
Travel Status
Travel
TRAVEL
STATUS
VALUE
Transducer
34
34.1
34.2
4-45, 6-11
Travel Status (DeCharacterization)
Travel (DeCharacterization)
FINAL_POSITION_VALUE
STATUS
VALUE
Transducer
17
17.1
17.2
4-44, 6-11
Trim Style 1 TRIM_STYLE_1 Transducer 84.9 4-39, 4-61
Trim Style 2 TRIM_STYLE_2 Transducer 84.10 4-39, 4-61
Travel Accumulator Alert Pt
TVL_ACCUM_ALRT_PT Transducer 77.4 4-34, 4-59
Travel Accumulator DB
TVL_ACCUM_DB Transducer 77.5 4-34, 4-59
Travel Active TRAVEL_ACTIVE Transducer 74.4 4-54
Travel Calibration Command TVL_CAL_CMD Transducer 45.1 4-48
Travel Calibration Program TVL_CAL_PROG Transducer 45.2 4-48
Travel Calibration Status TVL_CAL_STATUS Transducer 45.3 4-48
Travel Calibration Trigger TVL_CAL_TRIGGER Transducer 42.9 4-46
Travel Closed Alert Point
TVL_CLOSED_ALRT_PT Transducer 77.10 4-33, 4-59
Travel Closed Deadband
TVL_CLOSED_DB Transducer 77.11 4-33, 4-59
Travel Count
TVL_COUNT Transducer 43.1 4-47, 6-11
−Continued−
4
