Table 4-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Travel Crossover
TVL_CROSSOVER Transducer 43.4 4-47
Travel Cutoff Hi
FINAL_VALUE_CUTOFF_HI Transducer 15 4-25, 4-43
Travel Cutoff Lo
FINAL_VALUE_CUTOFF_LO Transducer 16 4-25, 4-43
Travel Deviation Alert Point
TVL_DEV_ALRT_PT Transducer 77.1 4-31, 4-59
Travel Deviation Deadband
TVL_DEV_DB Transducer 77.3 4-31, 4-59
Travel Deviation
TRAVEL_DEVIATION Transducer 52 4-31, 4-50
Travel Deviation Time
TVL_DEV_TIME Transducer 77.2 4-31, 4-59
Travel Factory Hi TVL_FAC_HI Transducer 43.5 4-47
Travel Factory Lo TVL_FAC_LO Transducer 43.6 4-47
Travel Hi Alert Point TVL_HI_ALRT_PT Transducer 77.16 4-32, 4-59
Travel Hi Calibration TVL_HI_CAL Transducer 43.2 4-47
Travel Hi Deadband TVL_HI_DB Transducer 77.17 4-32, 4-59
Travel Hi Hi Alert Point TVL_HI_HI_ALRT_PT Transducer 77.18 4-32, 4-59
Travel Hi Hi Deadband TVL_HI_HI_DB Transducer 77.19 4-32, 4-59
Travel History Active TVL_HISTORY_ACTIVE Transducer 74.6 4-54
Travel History Enable TVL_HISTORY_ENABLE Transducer 75.6 4-57
Travel Integral Deadzone TVL_INTEG_DEADZ Transducer 44.4 4-23, 4-47
Travel Integral Enable TVL_INTEG_ENABLE Transducer 44.1 4-23, 4-47
Travel Integral Limit Hi TVL_INTEG_LIM_HI Transducer 44.2 4-23, 4-47
Travel Integral Limit Lo TVL_INTEG_LIM_LO Transducer 44.3 4-23, 4-47
Travel Integral Gain
SERVO_RESET Transducer 19 4-23, 4-44
Travel IP Bias
TVL_IP_BIAS Transducer 43.7 4-47
Travel Lo Alert Point TVL_LO_ALRT_PT Transducer 77.14 4-32, 4-59
Travel Lo Calibration TVL_LO_CAL Transducer 43.3 4-47
Travel Lo Deadband TVL_LO_DB Transducer 77.15 4-32, 4-59
Travel Lo Lo Alert Point TVL_LO_LO_ALRT_PT Transducer 77.12 4-32, 4-59
Travel Lo Lo Deadband TVL_LO_LO_DB Transducer 77.13 4-32, 4-59
Travel MLFB Bias TVL_MLFB_BIAS Transducer 43.8 4-47
Travel MLFB Gain TVL_MLFB_GAIN Transducer 44.5 4-22, 4-47
Travel Open Alert Point TVL_OPEN_ALRT_PT Transducer 77.8 4-33, 4-59
Travel Open Deadband TVL_OPEN_DB Transducer 77.9 4-33, 4-59
Travel/Pressure Select TVL_PRESS_SELECT Transducer 41.1 4-25, 4-45
Travel/Pressure State TVL_PRESS_STATE Transducer 41.2 4-45, 6-11
Travel Proportional Gain
SERVO_GAIN Transducer 18 4-22, 4-44
Travel Sensor Motion
TRAVEL_SEN_MOTION Transducer 42.3 4-38, 4-46
Travel Tuning Set TVL_TUNING_SET Transducer 42.10 4-22, 4-46
Travel Units
TVL_UNITS Transducer 91 4-36, 4-63
Travel Velocity Gain
SERVO_RATE Transducer 20 4-22, 4-44
UBeta BETA (ubeta) PID 73 4-96
UGamma GAMMA (ugamma) PID 72 4-95
Unbalanced Area UNBALANCED_AREA Transducer 84.8 4-37, 4-61
Update Event UPDATE_EVT
AI 20 4-135
AO 29 4-78
DI 18 4-167
DO 25 4-156
ISEL 23 4-111
MAI 16 4-144
OS 23 4-124
PID 43 4-93
Resource 35 4-16
Transducer 7 4-42
−Continued−
