FloBoss 107 Inst
ruction M
anua
l
2-
14
Ins
tallation and Use
Revised J
une-2017
A
Loop power +
B
Power In +
C
Power In -
D
LOI Tx (Red)
E
LOI Rx (
W
hite)
F
LOI RTS
G
Ground (Black)
H
RS
-485 A
I
RS
-485 B
J
RS
-232 Tx
K
RS
-232 Rx
L
RS
-232 RTS
M
Ground
N
RTD Source
O
RTD +
P
RTD -
Q
RTD Return
R
Loop Output Power
S
Power Input
T
EIA-232 (RS-232) Local LOI Port
U
EIA-485 (RS-485) COM1
V
EIA-232 (RS-232) COM2
W
Reset Switch
X
Resistance Thermal Device (RTD)
Figure 2-7. CPU Module
R
S
T
U
V
W
X
B
C
D
E
F
G
A
H
I
J
K
L
M
N
O
P
Q
45
47
