FloBoss 107 Instruction Manual
7-2 Troubleshooting Revised June-2017
 Save the configuration and log data (refer to Section 7.3.4, Preserving
Configuration and Log Data).
 Note the order in which you remove components.
 Note the orientation of the components before you alter or remove
them.
 Read and follow all cautions in this manual.
When you finish troubleshooting, perform the restart procedure in Section
7.4.2, Restarting and Reconfiguring the FB107.
Caution
Failure to exercise proper electrostatic discharge precautions, such
as wearing a grounded wrist strap may reset the processor or
damage electronic components, resulting in interrupted operations.
If the FB107 is used in a control application, ensure the system is off-
line.
7.2 Graphical User Interface (GUI)
The FB107’s graphical user interface (GUI) provides visual clues to help
you diagnose problems.
Once you successfully log onto ROCLINK 800 and connect to the
FB107, the GUI displays (see Figure 7-1).
