FloBoss 107 Instruction Manual
3-4 Power Connections Revised June-2017
1
Valid for slot 7 only if a Comm module is installed in slot 1
2
Represents Base (Loop loading x Loading Factor)
Table 3-3. Power Consumption Worksheet
Power
1
Total Power
System Power (mW)
Field Power (mW)
Voltage
2
Input Voltage (V dc)
Field Voltage (V dc)
Total Voltage
Current
3
System Current mA
Communications mA (Average)
Total Current mA on Power System
Miscellaneous
4
Battery Voltage
Battery Capacity Amp/Hour
Depth of Discharge
Available Hours
Days of Autonomy
1
System Power represents the base or idle load; Field Power represents the active load; Total
Power is the sum of the two values, representing the maximum of all modules at all times.
2
Voltage indicates 12 V dc or 24 V dc Power Input module.
3
Current (calculated as Total Power / Input Voltage) represents the system current as well as any
added external current through communications devices.
4
Miscellaneous identifies several components:
 Battery Voltage: a given value from the manufacturer
 Battery Capacity Amp/Hr: a given value from the manufacturer
 Depth of Discharge: A percentage of battery power used.
 Available Hours: The number of hours the unit can be powered without external charging of the
power system.
 Days of Autonomy: the number of days the device can perform without external power, given the
estimated power requirements.
