FloBoss 107 Inst
ruction M
anua
l
Revised June-20
17
Inputs and Outputs
4-
21
TERMINATION RESISTOR
120 OHM
FIELD
DEVICE
+
-
EXTERNAL
POWER
USER SUPPLIED
A
B
Figure 4-18. Application Module Wiring to Single Field Device
Note
:
To provide internal power to a field device, conne
ct the positive
wire to the PWR connection and the nega
tive wire to the GND
connection on the APP485 module.
However, this may not be
appropriate in all circumstances.
Check with your local Remote
Automation Solutions representative f
or the solution relevant to
your situation.
FIELD
DEVICE
EXTERNAL
POWER
POWER
EXTERNAL
-
+
DEVICE
FIELD
POWER
EXTERNAL
DEVICE
FIELD
USER SUPPLIED
120 OHM
TERMINATION RESISTOR
+
+
A
B
A
B
A
B
-
-
Figure 4-19. Application Module Wiring to Multiple Field Devices
