Table 10 Technical data, 60 Hz - High ambient condenser
Model ET018 ET024 ET036
Compressor type Scroll Scroll Scroll
Net capacity data based on 80°F (26.6°C) DB/67°F (19.4°C) WB indoor ambient - BTUH (kW)*
Outdoor ambient
85°F
(29.4°C)
Total 19600 (5.7) 22600 (6.6) 34400 (10.1)
Sensible 15800 (4.6) 17200 (5.0) 24400 (7.2)
95°F
(35.0°C)
Total 18700 (5.5) 21700 (6.4) 32900 (9.6)
Sensible 15500 (4.5) 16900 (5.0) 23800 (6.9)
105°F
(40.6°C)
Total 17700 (5.2) 20700 (6.1) 31300 (9.1)
Sensible 15200 (4.5) 16600 (4.9) 23100 (6.8)
115°F
(46.1°C)
Total 16700 (4.9) 19600 (5.7) 29500 (8.6)
Sensible 15800 (4.7) 16200 (4.8) 22600 (6.7)
Net capacity data based on 75°F (23.9°C) DB/62.5°F (16.9°C) WB indoor ambient - BTUH (kW)*
Outdoor ambient
85°F
(29.4°C)
Total 18100 (5.3) 20800 (6.1) 32100 (9.4)
Sensible 15200 (4.5) 16800 (4.9) 24100 (7.1)
95°F
(35.0°C)
Total 17200 (5.0) 20000 (5.9) 30700 (9.0)
Sensible 14900 (4.4) 16500 (4.8) 23400 (6.9)
105°F
(40.6°C)
Total 16400 (4.8) 19000 (5.6) 29300 (8.6)
Sensible 15600 (4.6) 16100 (4.7) 22600 (6.6)
115°F
(46.1°C)
Total 15700 (4.6) 18000 (5.3) 27600 (8.1)
Sensible 14900 (4.3) 15700 (4.6) 21900 (6.4)
Evaporator Air Flow - Dry Coil
External Static Pressure CFM (m
3
/hr)
0.0 - IN WG (0.0 Pa) 870 (1480) 930 (1580) 1300 (2210)
0.1 - IN WG (25 Pa) 830 (1410) 880 (1500) 1220 (2070)
0.2 - IN WG (50 Pa) 780 (1320) 840 (1430) 1130 (1920)
0.3 - IN WG (75 Pa) 750 (1260) 800 (1360) 1030 (1750)
0.4 - IN WG (100 Pa) 670 (1140) 730 (1240) 920 (1560)
0.5 - IN WG (125 Pa) 590 (1000) 650 (1100) 820 (1390)
Evaporator Air Flow - Wet Coil
External Static Pressure CFM (m
3
/hr)
0.0 - IN WG (0.0 Pa) 850 (1440) 910 (1550) 1200 (2040)
0.1 - IN WG (25 Pa) 810 (1380) 860 (1460) 1120 (1900)
0.2 - IN WG (50 Pa) 770 (1310) 820 (1390) 1030 (1750)
0.3 - IN WG (75 Pa) 720 (1220) 780 (1320) 940 (1600)
0.4 - IN WG (100 Pa) 650 (1100) 710 (1210) 850 (1440)
0.5 - IN WG (125 Pa) 570 (970) 620 (1050) 750 (1270)
Evaporator
Motor, Hp (kW) 0.25 (0.19) 0.25 (0.19) 0.25 (0.19)
Filter Sizes - Quantity, in. (cm)
16 x 32.5 x 2 - one
(40.6 x 82.5 x 5)
16 x 32.5 x 2 - one
(40.6 x 82.5 x 5)
16 x 32.5 x 2 - one
(40.6 x 82.5 x 5)
Drain Connection - ID, in. 3/4 3/4 3/4
Weight w/o Economizer, Ib (kg) 330 (150) 330 (150) 330 (150)
Weight w/ Economizer, Ib (kg) 350 (159) 350 (159) 350 (159)
* Based on rated airflow at 0.2 IN WG (50 Pa) external static and no outside air.
