Note
Not all alarms are applicable to all transmitters. For more information, see the transmitter
configuration manual for your transmitter.
B.7.7 Status Word 7
Bit number Status description
0 K1/FCF Combination Unrecognized
1 Warming Up
2 Low Power (A031)
3 Tube Not Full (A033)
4 Smart Meter Verification / Outputs in fault (A032)
5 Smart Meter Verification / Outputs at last value (A131)
6 PIC UI EEPROM Error (A133)
7 NVM Initialized (transmitter)
8 Power Outage (A136)
9 NOC Measurements Paused (A137)
10 TBR Active (A138)
11 External Water Cut Out of Range (A139)
12 TMR Active (A140)
13 One or more DDC Triggers Completed (A141)
14 Smart Meter Verification failed (A34)
15 Smart Meter Verification aborted (A35)
User Guide Device profile
MMI-20019808 January 2019
User Guide 71
