Table B-23: Smart Meter Verification abort codes
Abort code Description Suggested action
1 User-initiated abort None required. Wait for 15 seconds before
starting another test.
3 Frequency drift Ensure that temperature, flow, and density are
stable, and rerun the test.
5 High drive gain Ensure that flow is stable, minimize entrained gas,
and rerun the test.
8 Unstable flow Enter that flow is stable and rerun the test.
13 No factory reference data for meter verification
test performed on air
Contact Micro Motion customer service and
provide the abort code.
14 No factory reference data for meter verification
test performed on water
Contact Micro Motion customer service and
provide the abort code.
15 No configuration data for meter verification Contact Micro Motion customer service and
provide the abort code.
Other General abort. Repeat the test. If the test aborts again, contact
Micro Motion customer service and provide the
abort code.
Table B-24: Smart Meter Verification state at abort
Value Description
0 Inactive
1 In progress
15 Debug mode
16 Measurement completed
B.7 Status words
B.7.1 Status Word 1
Bit number Status description
0 Core EEPROM Checksum Error (Config, Powerdown, Program)
1 Core RAM Test Error
2 Real-Time Interrupt Failure
3 Sensor Failure (A003)
4 Temperature Sensor Out-of-Range (A004)
Device profile User Guide
January 2019 MMI-20019808
66 Micro Motion EtherNet/IP Module
