Emerson Micro Motion User Manual

A Connector pin assignments
A.1 Ethernet connector
Pin Signal
Housing Cable shield
1 TD+
2 TD–
3 RD+
4 Termination
5 Termination
6 RD–
7 Termination
8 Termination
A.2 Power connector
Pin Description
1 24 VDC
2 Ground
• Use 60/75 or 75 x C copper (CU) wire only.
• The terminal tightening torque must be between 5 and 7 lbs-in (0.5 to 0.8 Nm).
A.3 Micro Motion Ethernet Config Tool installation
(optional)
Related tasks
Install the Ethernet Config Tool
User Guide Connector pin assignments
MMI-20019808 January 2019
User Guide 31

Emerson Micro Motion Specifications

General

Category	Measuring Instruments
Manufacturer	Emerson
Brand	Micro Motion
Type	Coriolis Flow Meter
Output	4-20 mA, HART, Foundation Fieldbus, Profibus, Modbus
Power Supply	24 V DC
Material	Stainless Steel, Hastelloy
Process Connection	Flanged, Threaded
Certifications	ATEX, IECEx, CSA, SIL
Pressure Rating	Varies by model; up to 10, 000 psi (690 bar)
Temperature Range	Varies by model; -400 to 750°F (-240 to 400°C)
