SAG582127000 System Application Guide
Issue AF, February 26, 2014 Spec. No. 582127000 (Model 721
NPBB)
Page 2 of 125
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
• Module Mounting Shelf (Spec. No. 588705300)
The system may contain one or more Spec. No. 588705300 module mounting
shelves, each of which houses rectifier modules and optional DC-DC converter
modules. Refer to Power Data Sheet PD588705300 for more information.
• Rectifier Modules (for use in Spec. No. 588705300)
The system contains rectifier modules; which provide load power, battery float
current, and battery recharge current during normal operating conditions. Refer
to the Rectifier Instructions (UM1R482000E3) for more information.
• Optional DC-DC Converter Modules (for use in Spec. No. 588705300)
Where +24V DC load power is also required, DC-DC converter modules are
available. Refer to the Converter Instructions (UM1C48241500) for more
information.
(E/W Spec. No. 588705000
Module Mounting Shelves) (E/W Spec. N
o. 588705300 Module
Mounting Shelves)
Main Bay Supplemental B
ayMain Bay Supplement
al Bay
