Quick Panel Operator User Manual Section 1
GFK-2847AA Jan 2023
Overview 6
IC755CxS15CDx Specifications
Item
Specification
Processor
Freescale i.MX535 (1 GHz ARM Cortex A8)
Memory
RAM
DDR3 SDRAM 1 GB
ROM
SLC NAND 512 MB
SRAM
512 KB (with battery backup)
Operating System
Microsoft Windows Embedded Compact 7
Display
Type
15" Standard TFT LCD
Resolution
1024(W) x 768(H) pixels XGA
Color
65,536
Brightness
310 cd/m
2
Backlight
LED
Touchscreen
Touch Panel Type
Projected capacitive
Multi-touch
Two-point
Communication
s
Ethernet Port
2x 10/100Base-T (RJ-45)
Serial Port
1x RS-232 UART port
1x RS-232/485 port (2x 5-pin connector)
USB, Host
2x USB 2.0 (Type-A) maximum power (5 V at 0.5 A)
USB, Device
1x USB 2.0 (mini Type-B)
Storage
1x SD/SDHC card slot
Audio
1x Line Out (Stereo) (3.5 mm jack)
Noise Immunity
Noise voltage
1500 V p-p
Pulse duration
1µs
Rise time
1ns
Input power
Rated Voltage
12/24 Vdc ±20% (3-pin connector)
Power
Consumption
30 W maximum, 2.5 / 1.25 A
Frame Ground (FG)
Frame GND is connected internally to Signal GND
Dimensions (L×W×D)
399 × 323 × 70 mm (15.71 × 12.72 × 2.76 in)
Weight
4.46 kg (9.83 lbs.)
Mounting
Options
Panel Cutout
Dimensions
379 × 305 mm (14.92 × 12.01 in)
VESA Mount
100 x 100 mm (3.94 x 3.94 in)
