Emerson QuickPanel+ IC755CxS06RDx - 1.1 Specifications; 1.1.1 Physical Specifications and Mounting Options

Quick Panel Operator User Manual Section 1
GFK-2847AA Jan 2023
Overview 2
1.1 Specifications
1.1.1 Physical Specifications and Mounting Options
IC755CxS06RDx Specifications
Item
Specification
Processor
Freescale i.MX535 (1 GHz ARM Cortex A8)
Memory
RAM
DDR3 SDRAM 512 MB
ROM
NAND FLASH 256 MB(IC755CxS06RDx-Ax)
NAND FLASH 512 MB(IC755CxS06RDx, -Bx, -Cx)
SRAM
512 KB (with battery backup)
Operating System
Microsoft Windows Embedded Compact 7
Display
Type
5.7” TFT LCD
Resolution
320(W) x 240(H) pixels QVGA
Color
65,536
Brightness
375 cd/m
2
Backlight
LED
Touchscreen
Touch Panel Type
Analog Resistive
Multi-touch
Single-touch
Communications
Ethernet Port
1x10Base-T / 100Base-TX
Serial Port
1x RS-232C (COM1) (5-pin connector)
USB, Host
2x USB 2.0 (Type-A) maximum power (5 V at 0.5 A)
USB, Device
1x USB 2.0 (mini Type-B)
Storage
1x SD/SDHC card slot
Audio
1x Mic In (Mono) (3.5 mm jack),
1x Line Out (Stereo) (3.5 mm jack)
Noise Immunity
Noise Voltage
1500 V p-p
Pulse Duration
1µs
Rise Time
1ns
Input power
Rated Voltage
24 Vdc ±20% (3-pin connector)
Power
Consumption
15 W maximum
Frame Ground
(FG)
Frame Ground (GND) is connected internally to Signal
GND
Dimensions (L×W×D)
192 × 137 × 36 mm (7.56 × 5.39 × 1.42 in)
Weight
0.7 Kg (1.54 lb.)
Mounting
Options
Panel Cutout
Dimensions
183.50 × 128.50 mm (7.22 × 5.06 in)
VESA Mount
75 x 75 mm (2.95 x 2.95 in)
