Emerson QuickPanel+ IC755CxS06RDx - 3.14.2 Enable or Disable SNMP Agent; 3.14.3 Export MIB to SD Card

Quick Panel Operator User Manual Section 3
GFK-2847AA Jan 2023
Software 42
3.14.2 Enable or Disable SNMP Agent
SNMP communication is disabled by default on the QuickPanel
+
device
for security purposes. To enable or disable SNMP communication using
the QuickPanel
+
OS Utilities Settings tool refer to the procedure in Section
3.9.4, Enable or Disable SNMP Agent.
Note: Enabling or disabling SNMP communication is a one-time user configuration.
3.14.3 Export MIB to SD Card
With the SNMP Agent enabled on the QuickPanel
+
device, export the
QuickPanel
+
Management Information Base (MIB) QuickPanelMIB.mib file
to an SD Card.
NOTICE
It is highly recommended that you pre-load Emerson MIBs (GEIP-SMI.txt and GEIP-
PRODUCTS-MIB.txt in sequence) before loading the QuickPanelMIB.mib file into SNMP
Managers to avoid any MIB compiler errors.
Download the MIBs GEIP-SMI.txt and GEIP-PRODUCTS-MIB.txt from the Support Site.
QuickPanelMIB.mib may be copied from the QuickPanel+ device by performing the
following procedure.
To export the MIB to an SD Card
1. Insert a working SD Card into the external card slot on the
QuickPanel
+
device.
2. From the Start menu, select System, open the QuickPanel
+
Setup Tool, and select the SNMP Agent tab.
3. Copy the MIB file to the SD Card.
Figure 41: Copy MIB to SD Card
