Quick Panel Operator User Manual Section 5
GFK-2847AA Jan 2023
Mounting and Installation 78
5.7.7 SD Card Slot and Storage
The QuickPanel
+
is equipped with one standard SD Card port. SD/SDHC
memory cards are supported. The SD card slot is spring-loaded for easy
insertion and removal.
Note: Micro SD slot is not supported on the 6” display unit (IC755CxS06RDx).
Connectors: SD card slot (push in-push out method)
Card support: SD/SDHC memory card
Maximum capacity: 32 GB
Note: During insertion, observe the orientation of the SD card as displayed in the following figures.
Figure 79: SD Card Location IC755CxS06RDx
Figure 80: SD Card Location IC755CxW07CDx
