S4K2UC SERIES USER MANUAL | 25
10. Use two box assembly screws to install the cover onto the box, as shown in Figure 22.
Box
Screw (2 pcs) Cover
Figure 22: Installing the cover
11. Connect the other end of the UPS output line, neutral and ground cables to the load.
2.5.3 Connecting Battery Cables
1. Switch o the input breaker of the battery cabinet.
2. Take out the battery cable included with the battery cabinet.
3. Connect one end of the battery cable to the external battery connector on the rear panel of the UPS and connect the
other end to any battery port on the rear panel of the battery cabinet.
4. Switch on the battery breaker on the rear of the external battery cabinet.
5. Use the Conguration Program included with the UPS to specify the number of external battery cabinets connected
to the S4K2UC. See Table 14 for approximate battery run times.
2.6 Connecting Communication Cables
Communication cable connection includes: USB and option card cables.
2.6.1 Connecting USB Communication Cables
1. Take the USB communication cables out of the accessories box.
2. Insert one end of the USB communication cable into the USB port on the rear panel of the S4K2UC (see Figure 2).
3. Insert the other end of the USB communication cable into the USB port of the computer.
2.6.2 Installing the Optional IntelliSlot Card & Communication Cables
1. Remove the protective cover of the IntelliSlot port on the S4K2UC and set it aside.
2. Insert the IntelliSlot card into the IntelliSlot port and secure it with screws.
3. To connect any cable associated with a IntelliSlot card, refer to the user manual provided with the card.
To congure and use the IntelliSlot communication card, refer to the card’s user manual.
To Next Page
