S4K2UC SERIES USER MANUAL | 35
6.0 Battery Cabinet
Optional battery cabinets are available for the S4K2UC. The battery connectors and input breaker are on the battery
cabinet’s rear panel, as shown in Figure 27. For battery cabinet specications, refer to Table 12. For battery run times, refer
to Table 14.
Battery Connectors
Input Breaker
Figure 27: Battery cabinet
!
WARNING
Do not contact the battery connectors and ground without wearing protective gloves and clothing and taking other
precautions against electrical shock. The battery loop and AC input are not insulated, which may cause a dangerous
voltage between the battery connectors and ground.
