The motorised pot modes are given in the following table.
When this bit is set to 0 the motorised pot output is limited to positive values only (i.e. 0 to 100.0%). Setting it to 1 allows negative outputs
(i.e. ±100.0 %).
This parameter defines the time taken for the motorised pot function to ramp from 0 to 100.0%. Twice this time will be taken to adjust the output from
-100.0 % to +100.0 %.
This parameter can be used to restrict the output of the motorised pot to operate over a reduced range so that it can be used as a trim, for example.
9.21 Motorised pot mode
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range Regen 0 to 3
Default Regen 2
Update rate Background
Pr 9.21 Mode Comments
0 Zero at power-up
Reset to zero at each power-up.
Up, down and reset are active at all times.
1 Last value at power-up
Set to value at power-down when drive powered-up.
Up, down and reset are active at all times.
2
Zero at power-up and only change
when drive running
Reset to zero at each power-up.
Up and down are only active when the drive is running (i.e. inverter active).
Reset is active at all times.
3
Last value at power-up and only
change when drive running
Set to value at power-down when drive powered-up.
Up and down are only active when the drive is running (i.e. inverter active).
Reset is active at all times.
9.22 Motorised pot bipolar select
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
9.23 Motorised pot rate
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range Regen 0 to 250 s
Default Regen 20
Update rate Background
9.24 Motorised pot scale factor
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range Regen 0.000 to 4.000
Default Regen 1.000
Update rate 4ms x number of menu 9 or 12 functions active
