184 Unidrive SP Regen Installation Guide
www.controltechniques.com Issue Number: 2
*SP2404 Power and current ratings
All Unidrive SP models are dual rated except for the SP2404 which only has a Heavy Duty rating. However, if the current limits in Pr 4.05 to Pr 4.07
are set to a maximum of 110% and the switching frequency is greater than 3kHz, then the drive can be used at a maximum continuous current higher
than the Heavy Duty rating. See the Normal Duty ratings in Table 10-1, Table 10-2 and Table 10-3. Normal Duty ratings exist for the SP2404 above
3kHz when the overload is reduced from the default value 165% in open loop or 175% in closed loop, to 110%.
If the current limits in Pr 4.05 to Pr 4.07 are set higher than 110% then the Heavy Duty current ratings are applicable.
Table 10-2
Maximum permissible continuous output current @ 40°C (104°F) ambient with IP54 insert and standard fan fitted
Model
Normal Duty
Heavy Duty
Nominal
rating
Maximum permissible continuous output current
(A) for the following switching frequencies
Nominal
rating
Maximum permissible continuous output current
(A) for the following switching frequencies
3kHz 4kHz 6kHz 8kHz 12kHz 16kHz 3kHz 4kHz 6kHz 8kHz 12kHz 16kHzkW hp kW hp
SP1201 1.1 1.5 5.2 0.75 1.0 4.3
SP1202 1.5 2.0 6.8 1.1 1.5 5.8
SP1203 2.2 3.0 9.6 9.3 8.2 7.3 1.5 2.0 7.5 7.3
SP1204 3.0 3.0 11.0 10.6 9.7 9.0 7.7 6.6 2.2 3.0 10.6 10.5 9.7 9.0 7.7 6.6
SP2201 4.0 5.0 15.5 3.0 3.0 12.6
SP2202 5.5 7.5 22.0 20.7 18.0 15.7 4.0 5.0 17.0 15.5
SP2203 7.5 10 24.5 23.7 22.0 20.5 17.9 15.6 5.5 7.5 24.2 23.4 21.8 20.3 17.7 15.5
SP1401 1.1 1.5 2.8 0.75 1.0 2.1
SP1402 1.5 2.0 3.8 2.9 1.1 2.0 3.0 2.9
SP1403 2.2 3.0 5.0 3.9 2.9 1.5 3.0 4.2 3.9 2.9
SP1404 3.0 5.0 6.9 6.5 5.4 3.9 2.9 2.2 3.0 5.8 5.4 3.9 2.9
SP1405 4.0 5.0 8.3 7.3 5.8 4.7 3.2 2.3 3.0 5.0 7.6 7.3 5.8 4.7 3.2 2.3
SP1406 5.5 7.5 8.3 7.3 5.8 4.7 3.2 2.3 4.0 5.0 8.2 7.3 5.8 4.7 3.2 2.3
SP2401 7.5 10 15.3 13.3 10.1 7.9 5.5 10 13.0 12.6 9.4 7.3
SP2402 11 15 20.1 18.4 15.6 13.4 10.1 7.9 7.5 10 16.5 14.9 12.3 9.3 7.2
SP2403 15 20 21.7 19.7 16.4 13.9 10.2 7.7 11 20 21.6 19.6 16.4 13.8 10.2 7.7
SP2404* 15 20 20.1 17.7 14.0 11.2 7.3 4.6 15 20 20.1 17.7 14.0 11.2 7.3 4.6
