These three bits control the motorised pot. The up and down inputs increase and decrease the output at the programmed rate respectively. If both up
and down are active together the up function dominates and the output increases. If the reset input is one, the motorised pot output is reset and held
at 0.0%.
9.25 Motorised pot destination
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Regen Pr 0.00 to Pr 21.51
Default Regen Pr 0.00
Update rate Background
9.26 Motorised pot up
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
9.27 Motorised pot down
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
9.28 Motorised pot reset
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
9.29 Binary sum ones input
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
9.30 Binary sum twos input
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
