Emerson SP3403 - Motor Thermistor Trip; Motor Thermistor Short Circuit; Power Module Unidentified Trip; Onboard PLC Program Attempted Divide by Zero

Safety
Information
Introduction
Product
information
System
design
Mechanical
installation
Electrical
installation
Getting
started
Optimisation Parameters
Technical
data
Component
sizing
Diagnostics
Unidrive SP Regen Installation Guide 213
Issue Number: 2 www.controltechniques.com
th Motor thermistor trip
24
Check regen inductor temperature
Check thermistor continuity
Set Pr 7.15 = VOLt and reset the drive to disable this function
thS Motor thermistor short circuit
25
Check regen inductor wiring
Replace regen inductor thermistor
Set Pr 7.15 = VOLt and reset the drive to disable this function
Unid.P Power module unidentified trip
110
Check all interconnecting cables between power modules
Ensure cables are routed away from electrical noise sources
UP ACC Onboard PLC program: cannot access Onboard PLC program file on drive
98
Disable drive - write access is not allowed when the drive is enabled
Another source is already accessing Onboard PLC program - retry once other action is complete
UP div0 Onboard PLC program attempted divide by zero
90 Check program
UP OFL Onboard PLC program variables and function block calls using more than the allowed RAM space (stack overflow)
95 Check program
UP ovr Onboard PLC program attempted out of range parameter write
94 Check program
UP PAr Onboard PLC program attempted access to a non-existent parameter
91 Check program
UP ro Onboard PLC program attempted write to a read-only parameter
92 Check program
UP So Onboard PLC program attempted read of a write-only parameter
93 Check program
UP udf Onboard PLC program un-defined trip
97 Check program
UP uSEr Onboard PLC program requested a trip
96 Check program
UV DC bus under voltage threshold reached
1
Check AC supply voltage level
Drive voltage rating (Vac) Under voltage threshold (Vdc)
200 175
400 350
575 435
690 435
Trip Diagnosis
