EMS AIRFLOW Prophylaxis Master User Manual

ENGLISH
FB-618/AU – rev.E – ed.2019/08
42/48
9. TECHNICAL DESCRIPTION
Manufacturer
EMS ELECTRO MEDICAL SYSTEMS SA, CH-1260 Nyon, Switzerland
Models
AIRFLOW Prophylaxis Master, product code FT-229
Classification IEC 60601-1
Electrical Insulation Class-I
Applied part Type B
IP20 Control unit
IP21 Foot pedal
Classification EU MDD
93/42/EEC
Medical Device Class IIa
Essential Performance
This medical device, in the meaning of the EU MDD 93/42 has no Essential Performance
Operating mode
Continuous operation
Power supply
100-240Vac, 50-60Hz, 4A max.
Power consumption
OFF-mode / Stand-by: 0.5W max.
Max: 700VA
Ultrasonic module
Max Output Power: 8W under fully-loaded mechanical condition.
Frequency: 24-32kHz.
Primary tip vibration excursion: 200um max.
Fuse
5A, T (slow), 250Vac, H type (=T5H250V)
Wireless communication
module
Max 8 dBm EIRP, 2.4GHz band, Bluetooth
®
radio module
Weight
Control Unit 5kg max. (full operating condition)
Foot pedal: 0.35kg max. (wireless pedal)
Dimensions
Control Unit: Height: 245 mm, Width: 260 mm, Length: 290 mm
Wireless pedal: Diameter 135 mm, Height 35 mm
Operating conditions
(device)
Temperature: 10°C to 35°C
Humidity: 30% to 75%
Altitude: Max 2000m
Storage conditions
(application box)
Temperature: up to 40°C
Storage conditions
Temperature: -10°C to 30°C, no water inside
Humidity: 10% to 95% not condensed
Pressure: 500hPa to 1060hPa
Transport conditions
Temperature: -29°C to 38°C, no water inside
Humidity: 10% to 95% not condensed
Pressure: 500hPa to 1060hPa
Input fluids
Water: pressure 2-5bar, temperature 10-30°C, salinity 0.2% max., hardness from 8 to
12°dH, minimum flow-rate 100ml/min, RECTUS 20KA connector type. EN-1717 compliant
water network/inlet is required.
Air: pressure 4.5-7bar, dry-only (humidity 1.032g/m3 max.), oil filtered 0.1mg/m3 max.,
minimum flow-rate 20 Nl/min at 4.5bar, RECTUS 21KA connector type
Output fluids
Water: min. 40ml/min. for AIRFLOW
®
, min. 30ml/min. for PIEZON
®
Air: max pressure 5bar for Airflow
Shelf life / lifetime
PIEZON
®
and NIGHT CLEANER bottles: 5 years
Handpieces (main bodies): 1000 sterilization cycles
CombiTorque
®
: 1000 sterilization cycles
Expected service life
Device: 7 years, having regular yearly preventive maintenance

EMS AIRFLOW Prophylaxis Master Specifications

General

Water Flow Rate	Adjustable
Powder Flow Rate	Adjustable
Technology	AIRFLOW, PERIOFLOW, PIEZON
Water Supply	Integrated water tank
Control	Foot control
Handpieces	AIRFLOW, PERIOFLOW, PIEZON
Water tank capacity	Approx. 800 ml
Water pressure	1 - 5 bar (100 - 500 kPa)
Operating mode	Continuous
Type	Air polishing system
Powder Type	Erythritol, Glycine
Nozzle Types	Standard, Perio
Power Supply	100-240 V, 50/60 Hz
