EMS FIRECELL User Manual

Page 38 of 40
Device Type
Radio Hub
RCC
Optical Detector
Optical Detector
Manual Call Point
Optical Detector
Optical Detector
Manual Call Point
Optical Detector
Heat CS Detector
Optical Detector
Heat A1R Detector
Optical Detector
Sounder
Sounder
Sounder Beacon
Loop / Address
Loop 1 Address 1
Loop 1 Address 2
Loop 1 Address 3
Loop 1 Address 4
Loop 1 Address 5
Loop 1 Address 6
Loop 1 Address 7
Loop 1 Address 8
Loop 1 Address 9
Loop 1 Address 10
Loop 1 Address 11
Loop 1 Address 12
Loop 1 Address 13
Loop 1 Address 14
Loop 1 Address 15
Loop 1 Address 16
Shown On Display
N/A
L1 A002 19dB
L1 A003 35dB
L1 A004 45dB
L1 A005 17dB
L1 A006 19dB
L1 A007 30dB
L1 A008 32dB
L1 A009 31db
L1 A010 18dB
L1 A011 45dB
L1 A012 45dB
L1 A013 42dB
L1 A014 38dB
L1 A015 45dB
L1 A016 19dB
Acceptable Level
An example of a display showing the levels for a system which does not have the required signal levels
is shown below:
Meeting the acceptable signal levels shown ensures the immunity to site attenuation (path loss) is met
as required in Clause 4.2.1 and Annexe B of EN54-25.
©2019 EMS Ltd. All rights reserved. MK98 Iss17 05/04/2019 AJM

EMS FIRECELL Specifications

General

Frequency	868 MHz
Operating Temperature	-10°C to +55°C
Communication	Wireless
Compliance	EN54-25
Devices Supported	Sounders
Power Supply	Lithium battery
Humidity Range	Up to 95% RH, non-condensing
Compatibility	EMS Firecell System
Type	Wireless Fire Alarm
