EMS FIRECELL User Manual

Page 7 of 40©2019 EMS Ltd. All rights reserved. MK98 Iss17 05/04/2019 AJM
RESET
LOGONBACK
HEALTHY
FA U LT
SYS FAULT
RF1 RF2
Radio Cluster Communicator
Log On Button
Ident Number
RevX DD/MM/YY
1d872
IDENT
Wireless Door Control (WDC)
Log on button
Ident Number
RevX DD/MM/YY
1d872
Wireless Remote Indicator Module (RIM)
www.emsgroup.co.uk
Wireless Detector Base
PRESS HERE TO
LOG ON
Part No: FCZ-170-111
Wireless Input / Output Unit
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT 1 INPUT 2
LED
ENABLE
PO WER
INPUT 1
INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1
EXPAN2
RELAY ON RELAY ON
2
4
8
16
32
ANTENNA
KEEP CABLES AWAY FROM THIS AREA
Log on button
device
unpowered
(pins unlinked)
device
powered
(both pins linked)
Power jumper
Ident Number
RevX DD/MM/YY
1d872
Ident Number
RevX DD/MM/YY
1d872
Log on button
!
Note: the WDC is logged on to the system
is an input/output device type
!
Note: the Wireless RIM is logged on to the
system is an input/output device type
Status LED

EMS FIRECELL Specifications

General

Frequency	868 MHz
Operating Temperature	-10°C to +55°C
Communication	Wireless
Compliance	EN54-25
Devices Supported	Sounders
Power Supply	Lithium battery
Humidity Range	Up to 95% RH, non-condensing
Compatibility	EMS Firecell System
Type	Wireless Fire Alarm
