EMS 5000 FIREPOINT
©2015 EMS Security Group Ltd. All rights reserved. TSD258 Iss 3 25/06/15 AJM
15
FIGURE 1
16 Press Yes key twice and the screen will now
display:
17 Press No key three times and the screen will
now display:
Note: After logging the device on to the system there will be two
faults: -
1
st
fault is processor reset. (Just silence and reset E.G. Page 3)
2
nd
fault is the Tamper. (Make sure the device tamper is clear then
silence and reset E.G. page 3)
18 After the faults have been cleared turn the
Control key switch to the off position and the
screen will now display:
|Slot is :IN USE |
>Logon is DISABLED<
| /\/\/\/\/\/\/\/\/\/\/\/\/\/\/\/\ |
01 FAULT TOT 02
Default Device 125
ZONE 01 DEVICE 125
To Next Page
