Nivector FTI26
14 Endress+Hauser
Connector
Dimensions mm (in)
Connection plug with PPSU plastic housing cover
A0021859
9 Valve plug M16, NPT ½"
Weight
• Plastic with M12 plug: 118 g (4.162 oz)
• Plastic with valve plug120 g (4.232 oz):
• Stainless steel with M12 plug240 g (8.465 oz):
• Stainless steel with valve plug: 243 g (8.465 oz)
• Stainless steel with M12 plug and protection cover: 288 g (10.158 oz)
Materials
Wetted materials
Component part Material Product Configurator
Sensor 316L (1.4404), ECTFE
1)
Order code 110, option WDJ
Polycarbonate Order code 110, option WDG
Protector G 1½" Material PBT-GF
2)
O-ring EPDM
Order code 620, option PA
Protector R 1½" Order code 620, option PB
1) The material ECTFE meets the requirements of EU 1935/2004, 10/2011, 2023/2006 and
FDA 21 CFR 177.1380
2) The material meets the requirements of EU 1935/2004, 10/2011, 2023/2006 and FDA 21 CFR 177.1660
Materials not in contact with process
Component part Material Product Configurator
Process connection 316L (1.4404/1.4435) Order code 110, option WDJ
Polycarbonate Order code 110, option WDG
Lock nut PA (black) Order code 620, option R7
Housing cover, valve plug PPSU
Design ring: PBT/PC
Order code 40, option U, V
M12 housing covers 316L (1.4404/1.4435) Order code 40, option N
PPSU
Design ring: PBT/PC
Order code 40, option M
Housing 316L (1.4404/1.4435) Order code 110, option WDJ
Polycarbonate Order code 110, option WDG
Nameplate lasered onto housing -
Ground terminal (optional) 304 (1.4301) See Ex approval, order code 10 → 21
Protection cover (optional) Polycarbonate See Ex approval, order code 10 → 21
Endress+Hauser supplies DIN/EN process connections with threaded connection in stainless
steel in accordance with AISI 316L (DIN/EN material number 1.4404 or 14435). In terms of
their stability-temperature property, the materials 1.4404 and 1.4435 are grouped in EN
1092-1 table 18 under 13E0. The chemical composition of the two materials can be identical.
