Nivector FTI26
Endress+Hauser 11
Environment
Ambient temperature range
90 (194)
80 (176)
70 (158)
60 (140)
50 (122)
40 (104)
30 (86)
20 (68)
10 (50)
0 (32)
1
T
T
40 (104)
0 (32)
10 (50)
20 (68)
30 (86) 50 (122) 90 (194)
80 (176)
70 (158)
60 (140)
p
a
A0036858
1) Ex devices
Tp) Process temperature = °C (°F)
Ta) Ambient temperature = °C (°F)
Storage temperature
–25 to +85 °C (–13 to +185 °F)
Pressure: 1 bar abs. (14.5 psi)
Relative humidity
0 to 100 %
Climate class
DIN EN 60068-2-38/IEC 68-2-38: Test Z/AD
Altitude
Up to 2 000 m (6 600 ft) above sea level
Degree of protection
• IP65/67 NEMA Type 4X Enclosure (M12 plug for plastic housing cover)
• IP66/68/69 NEMA Type 4X/6P Enclosure (M12 plug for metal housing cover)
• IP65 NEMA Type 4x Enclosure (ISO4400 M16/NPT ½" valve plug for plastic housing cover)
Shock resistance
In accordance with EA inspection, prEN 60068-2-27:2007: a = 300 m/s
2
= 30 g, 3 planes x 2
directions x 3 shocks x 18 ms
Vibration resistance
In accordance with Fh inspection, EN 60068-2-64:2008: a(RMS) = 50 m/s
2
, f = 5 to 2 000 Hz, t = 3
planes x 8 h
Cleaning
Resistant to typical cleaning agents from the outside. Passed Ecolab test.
Electromagnetic
compatibility
The electromagnetic compatibility requirements outlined in the IEC/EN 61326 series for "industrial
environments" are fulfilled when the device is installed in metallic vessel or metallic pipes. Emission
requirements for class B equipment are met. For details, refer to the Declaration of Conformity.
If the device is installed in plastic structures, its function may be influenced by strong
electromagnetic fields. Emission requirements for class A equipment are met (only for use in
"industrial environments").
Reverse polarity protection
Integrated; no damage in the event of reverse polarity or short-circuit
