Commissioning Proservo NMS80
60 Endress+Hauser
7.5.2 Configuration of the 4-20mA inputs
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
POWER
i
B
B1-3 B4-8
1 2 3 4 5 6 7 8
C
1 2 3
4 5 6 7 8
C1-3 C4-8
A0032464
 30 Possible locations of the Analog I/O modules, which can be used as a 4-20mA input. The order
code of the device determines which of these modules is actually present.
Submenu: Setup → Advanced setup → Input/output → Analog I/O
1)
Parameter Meaning / Action
Operating mode Select 4..20mA input or HART master+4..20mA input
Process variable Select which process variable is transmitted by the connected device.
Analog input 0% value Define which value of the process variable corresponds to an input current of 4 mA.
Analog input 100% value Define which value of the process variable corresponds to an input current of 20 mA.
Process value Check whether the indicated value matches the actual value of the process variable.
1) There is a Analog I/O submenu for each Analog I/O module of the device.
