Proservo NMS81
38 Endress+Hauser
Process
Process temperature range
–200 to +200 °C (–328 to 392 °F)
Process pressure range
Housing type Process pressure range
Stainless steel 0 to 25 bar(2.5 MPa/0 to 362 psi)
Standard Rating bar MPa psi
JIS 10 K 14 bar 1.4 MPa 203 psi
20 K 25 bar 2.5 MPa 362 psi
DIN PN10/16 16 bar 1.6 MPa 232 psi
PN25/40 25 bar 2.5 MPa 362 psi
ASME Cl.150 19 bar 1.9 MPa 276 psi
Cl.300 25 bar 2.5 MPa 362 psi
JPI 150 lbs 15.9 bar 1.59 Mpa 231 psi
300 lbs 25 bar 2.5 MPa 362 psi
Medium density
0.430 to 2.000 g/cm
3
(27 to 125 lb/ft
3
)
Medium density difference
for interface measurement
0.1 g/cm
3
(6.24 lb/ft
3
)
Viscosity
0 to 5 000 mPa s
