Endress+Hauser Proservo NMS81 - Mechanical Construction; Dimensions; Weight

Proservo NMS81
40 Endress+Hauser
Mechanical construction
Dimensions
414 (16.8)
314 (12.36)
218 (8.58)
73 (2.87)
22 (0.87)
314 (12.36)
313.5 (12.34)
227.5 (8.96)
48 (1.89)
135 (5.31)
55 (2.17)
100.3 (3.95)
213.5 (8.41)
99 (3.9)
218 (8.58)
213.5 (8.41)
A0026821
The thickness of the flange (22 mm (0.87 in)) shows the specification of the 10K 150A RF
aluminium flange JIS B2220.
Weight
30 kg (66.1 lb)
