Density Settings for the density input
Signal type 220000-01 Select the signal type for the density input.
Channel ident. 220002-01 Identifier for the density input. User-defined text, 6 char-
acters.
Unit 220003-01 Select the density unit.
Decimal point 220004-01 Select the number of decimal points that are used for the
density input.
Range start 220006-01 Configure what value corresponds to 0/4 mA.
Numerical value, max. 8 digits including decimal separa-
tor.
Meas. range end 220007-01 Configure what value corresponds to 20 mA.
Numerical value, max. 8 digits including decimal separa-
tor.
Digital 1/2 Setting up only required if the digital inputs (e.g. events)
are to be used.
Function 250000-00
250000-01
Select the desired function, → ä 33. Digital inputs are
High active, i.e. the described effect takes place when acti-
vated with High.
Low = -3 to +5 V
High = +12 to +30 V
Outputs Settings only needed if outputs (e.g. relay or analog out-
puts) should be used.
Universal output Settings for the universal output (current or pulse output).
Signal type 310000-00 Select the output signal for this channel.
Channel/value 310001-00 Select which channel or calculated value is to be output at
the output.
Start Value 310003-00 Configure what value corresponds to 0/4 mA.
Numerical value, max. 8 digits including decimal separa-
tor.
Full scale value 310004-00 Configure what value corresponds to 20 mA.
Numerical value, max. 8 digits including decimal separa-
tor.
Damping 310005-00 Time constant of the first order low pass for the output sig-
nal. This is used to prevent large fluctuations in the output
signal (can only be selected for the signal type 0/4 to 20
mA).
Numerical value, max. 8 digits including decimal separa-
tor.
Current start value 310022-00 Current that should be output at the start of the batch.
Only for the setting "channel/value = curve".
Start max. 310020-00 Two points are defined for the actuator curve. This is the
percentage value to reach the 20 mA value.
Only for the setting "Channel/value =Curve".
Stop max. 310021-00 Two points are defined for the actuator curve. This is the
percentage value to move away from the 20 mA value.
Only for the "Channel/value =Curve" setting.
Pulse Value 310006-00 The pulse value specifies what quantity an output pulse
corresponds to (e.g. 1 pulse = 5 liters).
Numerical value, max. 8 digits including decimal separa-
tor.
Pulse width 310007-00 The pulse width limits the max. possible output frequency
of the pulse output. Define a fixed or dynamic pulse
width.
