Batch Controller RA33 Appendix
Endress+Hauser 65
Decimal point 210006-00 Number of places after decimal point for the display.
e.g. measured value: 20.12348 l/s
The following can be displayed:
None: 20 l/s
One: 20.1 l/s
Two: 20.12 l/s
Three: 20.123 l/s
!
Note!
The value is rounded where necessary.
Counter unit 210005-00 Technical units of the count input, e.g. gal, cf, … .
Decimal point 210007-00 Number of digits after the decimal point for the counter.
Range start Transmitters convert the physical measured variable into
standardized signals.
Enter the beginning of the measuring range here.
Example: 0-100 m
3
/h of the sensor is transformed 4-20
mA: 0.
Decimal number, max. 8 digits including decimal separa-
tor.
Only for 0/4-20 mA.
Meas. range end Enter the end of the measuring range here, e.g. "100" for a
transmitter with 0-100 m
3
/h.
Decimal number, max. 8 digits including decimal separa-
tor.
Only for 0/4-20 mA.
Low flow cut off If the measured volume flow is below a configured value,
these quantities are not added to the counter.
If the input is scaled from 0 to y or the pulse input is used,
all values less than the configured value are not recorded.
If the input is scaled from -x to +y, all values around the
zero point (i.e. including negative values) are not
recorded.
Decimal number, max. 8 digits including decimal separa-
tor.
Temperature Settings for the temperature input.
Signal type 220000-00 Select the signal type connected.
Connection 220001-00 Configure whether RTD is to be connected with 3 or 4
wires.
Only for signal type Pt100, Pt500 or Pt1000.
Channel ident. 220002-00 Name of the measuring point connected to this input.
User-defined text, max. 6 characters.
Unit 220003-00 Specify the technical (physical) unit for the measuring
point connected to this input.
Decimal point 220004-00 Number of places after decimal point for the display.
Range 220005-00 Set the desired measuring range.
Only for Pt100, Pt500, Pt1000 or Platinum RTD(CvD).
!
Note!
A small measuring range increases the accuracy of temper-
ature measurement. Only for Pt100.
Range start 220006-00 Transmitters convert the physical measured variable into
standardized signals.
Enter the beginning of the measuring range here.
Only for 0/4 to 20 mA.
Decimal number, max. 8 digits including decimal separa-
tor.
Meas. range end 220007-00 Enter the end of the measuring range here.
Only for 0/4 to 20 mA.
Decimal number, max. 8 digits including decimal separa-
tor.
Default value 220009-00 Specify a fixed temperature value with which the device
should perform calculations.
Only for signal type = default value.
