Appendix Batch Controller RA33
64 Endress+Hauser
Reg. 9 to 11 Specify which values can be read out.
Value 500000-03 Choose the value which should be transmitted.
Analysis 500001-03 Select which counter (e.g. interval, daily counter etc.) is to
be transmitted.
Only if a counter has been selected for "Value".
Reg. 12 to 14 Specify which values can be read out.
Value 500000-04 Choose the value which should be transmitted.
Analysis 500001-04 Select which counter (e.g. interval, daily counter, etc.) is
to be transmitted.
Only if a counter has been selected for "Value".
………
Reg. 87 to 89 Specify which values can be read out.
Value 500000-29 Choose the value which should be transmitted.
Analysis 500001-29 Select which counter (e.g. interval, daily counter etc.) is to
be transmitted.
Only if a counter has been selected for "Value".
Device options Hardware and software options.
Optional outputs 990000-00
Communication 990001-00
Protocol 990007-00
Compensation+RTD 990009-00
Inputs Settings for the analog and digital inputs.
Flow Settings for the flow input.
Signal type 210000-00 Select the signal type connected.
4 to 20 mA (DP Flow):
Input for flow measurements based on the differential
pressure method (e.g. orifice plate)
Pulse U+IB+IC:
Input for active voltage pulses and contact sensors as per
EN 1434-2, Class IB + IC:
Pulse Cl. ID+IE:
Pulse input for contact sensors as per EN 1434-2, Class ID
+ IE:
Pulse (current):
Current pulse input: ≤ 8 mA Low level, ≥ 13 mA High
level.
Channel ident. 210001-00 Name of the measuring point connected to this input.
Customized text, 6 characters.
Pulse input 210002-00 Define whether the pulse input is a fast (up to 12.5 kHz)
or slow (up to 25Hz) pulse input.
Only if Pulse has been selected as the signal type.
Pulse Value 210003-00 Pulse factor = factor which, multiplied by an input
impulse, yields the physical value. Example: 1 pulse corre-
sponds to 5 m
3
-> enter "5" here. Decimal number, max.
8 digits including decimal separator.
Only if Pulse has been selected as the signal type.
Unit 210004-00 Specify the technical (physical) unit for the measuring
point connected to this input.
