Batch Controller RA33 Appendix
Endress+Hauser 63
Ethernet Set-up required, if you are using the Ethernet interface of
the unit.
DHCP 150002-00 The device can obtain its Ethernet settings by DHCP.
!
Note!
The settings determined are displayed only after the setup
is applied.
If the leasing time is configured long enough on the DHCP
server, the device always obtains the same IP address. The
PC software needs the determined IP address to set up the
connection.
IP address 150006-00 If you have configured DHCP = ’No’, enter the IP address
for the device here. This IP address is assigned by your
network administrator. Please contact him or her.
If DHCP = ’Yes’, the IP address obtained by DHCP is dis-
played here.
Subnetmask 150007-00 If you have configured DHCP = ’No’, enter the subnet
mask (you receive this from your network administrator).
If DHCP = ’Yes’, the subnet mask obtained by DHCP is
displayed here.
Gateway 150008-00 If you have configured DHCP = ’No’, enter the gateway
(you receive this from your network administrator).
If DHCP = ’Yes’, the gateway obtained by DHCP is dis-
played here.
Web server 470000-00 Switch the web server function on or off (=factory setting).
The current values can be displayed via Internet browser
only if the Web server is active.
!
Note!
Possible via the Ethernet interface only!
Modbus Configure the Modbus settings for the device.
!
Note!
For devices with Modbus (optional) only.
Device address 480000-00 Enter the device address where it should be possible to
reach this device in the bus.
Baudrate 480001-00 Set the transmission rate for communication.
Parity 480002-00 Please check that settings are compatible with the PC set-
tings!
Port 480004-00 Port via which the Modbus protocol can be addressed.
Byte sequence 480005-00 Byte addressing, i.e. the transmission sequence of the
bytes, is not specified in the MODBUS specification. For
this reason, it is important to coordinate the addressing
method between the master and slave during commission-
ing. This can be configured here.
Reg. 0 to 2 Specify which values can be read out.
Value 500000-00 Choose the value which should be transmitted.
Analysis 500001-00 Select which counter (e.g. interval, daily counter etc.) is to
be transmitted.
Only if a counter has been selected for "Value".
Reg. 3 to 5 Specify which values can be read out.
Value 500000-01 Choose the value which should be transmitted.
Analysis 500001-01 Select which counter (e.g. interval, daily counter etc.) is to
be transmitted.
Only if a counter has been selected for "Value".
Reg. 6 to 8 Specify which values can be read out.
Value 500000-02 Choose the value which should be transmitted.
Analysis 500001-02 Select which counter (e.g. interval, daily counter etc.) is to
be transmitted.
Only if a counter has been selected for "Value".
