Appendix Batch Controller RA33
72 Endress+Hauser
System Basic settings that are needed to operate the device (e.g.
date, time, communication settings etc.)
Language 010000-00 Select unit operating language.
PRESET 000044-00 Resets all parameters to the factory settings!
!
Note!
Can be changed via the service code only.
Clear memory 059000-00 Delete internal memory
Reset 059100-00 Reset analysis to 0.
Ethernet Set-up required, if you are using the Ethernet interface of
the unit.
MAC-Address 150000-00 MAC-Address
Port 150001-00 Communication with the PC software takes place via this
communication port.
!
Note!
If your network is protected by a firewall, you may need to
enable the port.
In this case, contact your network administrator.
Device options Hardware and software options of the device.
Activation code 000057-00 You can enter a code for activating the device options
here.
Inputs Settings for the analog and digital inputs.
Flow
Damping 210010-00 Factory setting: 0.0 s. The more unwanted interference is
superimposed over the measuring signal, the higher the
value should be set. Result: Fast changes are dampened/
suppressed.
Meas.val. corrct. Determines the correction values used to compensate for
measurement section tolerances.
Proceed as follows:
1. Measure the current measured value at the lower
measuring range.
2. Measure the current measured value at the upper
measuring range.
3. Enter the upper and lower target value and actual
value.
Range start Lower correction value.
Target value 210051-00 Enter the setpoint at the start of the measuring range here
(e.g. measuring range 0l/h to 100l/h: 0l/h).
Actual value 210052-00 Enter the actual measured value here (e.g. measuring
range 0l/h to 100l/h: 0.1l/h).
Meas. range end Upper correction value.
Target value 210054-00 Enter the target value at the end of the measuring range
here (e.g. measuring range 0l/h to 100l/h: 100 l/h).
Actual value 210055-00 Enter the actual measured value here (e.g. measuring
range 0l/h to 100l/h: 99.9l/h).
Fault mode Settings that define how this channel is to react under
fault conditions (e.g. cable open circuit, over range).
NAMUR NE 43 210060-00 Switch on/off monitoring of the 4 to 20 mA range as per
NAMUR Recommendation NE 43.
The following fault ranges apply when NAMUR NE43 is
enabled:
• ≤ 3.8 mA: Under range
• ≥ 20.5 mA: Over range
• ≤ 3.6 mA or ≥ 21.0 mA: Sensor error
• ≤ 2mA: Open circuit
