Endress+Hauser Turbimax CUS71D - Post-Installation Check

Turbimax CUS71D Installation
Endress+Hauser 11
Circular Clarifier
a0015232
Fig. 6: Basin configuration in circular clarifier
3.5 Post-installation check
• Sensor and cable undamaged?
• Cap undamaged?
• Compliance with permissible sensor installation position?
• Is the sensor installed in an assembly and is not suspended from the cable?
• Avoid moisture by rain by putting the protective cap on the assembly?
1/3
2/3
1
2
3
4
5
1/3
2/3
11
12
13
14
A
B
A View from top B Cross section
1 Surface skimmer 11 Sensor
2Walk way 12Hand rail
3 Sensor mounting 13 Surface skimmer
4 Bottom rake 14 Bottom rake
5 Rake direction
