Installation Turbimax CUS71D
8 Endress+Hauser
3.3 Installation instructions
3.3.1 Measuring system
A complete measuring system comprises:
• Ultrasonic sensor Turbimax CUS71D
• Multi-channel transmitter Liquiline CM44x
and optional:
• Weather protection roof CYY101
• Holder system Flexdip CYH11
• Fixed or rotatable immersion pipe Flexdip CYA112
a0014923
Fig. 3: Ultrasonic sensor with holder system and multi-channel transmitter
1
2
3
4
1
5
1 Holder system Flexdip CYH112 4 Assembly Flexdip CYA112
2 Multi-channel transmitter Liquiline CM44x 5 Ultrasonic sensor Turbimax CUS71D
3 Weather protection roof
