Technical Data Turbimax CUS71D
28 Endress+Hauser
10 Technical Data
10.1 Input
10.2 Performance characteristics
10.3 Environment
10.4 Process
10.5 Mechanical construction
Measured variable Standard sensor Interface
Sensor with wiper Interface
Sensor with wiper and turbidity
measurement
Interface
Turbidity
Measuring ranges Standard sensor 0.3 to 10.0 m (1.0 to 32 ft)
Sensor with wiper 0.3 to 10.0 m (1.0 to 32 ft)
Sensor with wiper and turbidity
measurement
0.3 to 10.0 m (1.0 to 32 ft)
0 to 50 (200) NTU
Measured error Interface 35 mm at 3.0 m
Turbidity 1 % of the measuring range at 50 NTU
Wavelength Interface 3 mm at 3.0 m
Turbidity 1 NTU
Measuring interval Adjustable
Calibration The sensor is factory calibrated delivered.
The "speed of sound" is adjustable and preprogrammed for the application "water".
Storage temperature -20 to 50 °C (-4 to 122 °F)
Degree of protection IP 68 (test conditions: 1 m (3.3 ft) water column during 60 days, 1 mol/l KCl)
Process temperature
range
1 to 50 °C (34 to 122 °F)
Process pressure 0.0 to 6 bar (0 to 87 psi) absolute
Dimensions See "Installation conditions"
Weight Standard sensor 1.02 kg (2.25 lb)
Sensor with wiper 1.25 kg (2.75 lb)
Sensor with wiper and turbidity
measurement
1.25 kg (2.75 lb)
Materials Sensor ABS and epoxy plastic
Wiper Rubber
Optical window Sapphire
Process connections G1 and NPT ¾''
