2.7 Setting Address (ID) of Dome Camera
To prevent wrong operation and malfunction, each dome camera must have a
unique address (ID).
When installing multiple dome cameras using a multiplexer, it is suggested that the
dome camera address match the multiplexer port number.
Example: Port 1 = Dome 1, Port 2 = Dome 2 … Port 16 = Dome 16.
If more than 16 dome cameras are installed using two or more multi-
plexers, ID of the dome camera should be ID of MUX x No. of camera IN.
(e.g. multiplexer ID = n, Camera IN = m, then ID of Dome = 16x (n-1) + m)
Refer to pages 49-52 for setting the dome camera address (ID) and protocol
selection.
